Description
- Workstation-grade Platform : 10-core 10th Gen Intel® Xeon®/Core™ i9/i7/i5/i3 Processor (CML-S) running with Intel® W480E chipset supports max 95W TDP CPU
- 2 DDR4 2933MHz Memory supports up to 64GB, optional with ECC
- 12V to 50V wide range DC Power Input with 80V Surge Protection
- 6 Independent GigE LAN with 4 IEEE 802.3at PoE+
- PCIe x8, PCIe x4 expansion supports up to 250W Power Budget
- Expansion : 2 PCIe x8, 1 PCIe x4, 1 M.2 Key B, 1 M.2 Key E, 2 Mini PCIe
- Storage : 4 2.5″ SSD Tray, 1 Micro SD Card, 1 M.2 Key M, 4 SATA III
- Display : VGA, DVI-D & 2 DisplayPort interfaces, up to 4K resolution
- 6-port USB 3.2 support up to 10Gbps data transfer
- Supports Configurable Software Ignition Power Control and TPM 2.0
