Description
-
-
- Workstation-grade Platform : Intel® Core™ i9/i7/i5/i3 Processor (14th gen, codename : RPL-S Refresh/RPL-S/ADL-S) running with Intel® R680E PCH supports max 65W TDP CPU
- Supports outstanding AI computing productivity by NVIDIA®/AMD graphics card, up to 200W power budget
- USB 3.2 Gen 2×2 offers a max speed of 20Gbps data transfer
- DC 12V to 50V wide range power input, Software Ignition Control
- 4 Independent 2.5GigE LAN IEEE 802.3at PoE+, 2 GigE LAN
- Supports multiple 5G/WiFi/BT/4G/LTE/GPRS/UMTS
- Supports Intel® vPro, TCC, Time-Sensitive Networking (TSN), and TPM 2.0
- Storage : 4 front-access 2.5″ SSD Tray, M.2 Key M
-
High-speed AI Inference Platform
- Workstation-grade Platform : Intel® Core™ i9/i7/i5/i3 Processor (14th gen, codename : RPL-S Refresh/RPL-S/ADL-S), up to 65W TDP CPU supported
- Dual DDR5 4800MHz SO-DIMM, up to 64GB Memory
- Supports performance hybrid architecture and advanced AI capabilities for smarter and faster applications
- Optional delivers outstanding AI computing productivity supporting max 6656 CUDA Cores, 52RT Cores, 208 Tensor Cores, delivers 15.6 TFLOPS RT Core performance, and 63.9 TFLOPS Tensor Core performance
- High-speed data transfer : PCIe 4.0 (16GT/s), USB 3.2 Gen 2×2 Type-C (20G), USB 3.2 Gen 2 (10G), SATA III (6G), 2.5GigE LAN (2.5G), GigE LAN (1G)
- Optional VHub One-Stop AIoT Solution Service supports OpenVINO based AI accelerator and advanced Edge AI applications
Compact Integration
- GigE Vision : 2 GigE LAN, 4 2.5GigE IEEE 802.3at PoE+ (25.5W/48V), optional with X-coded M12 Connector
- USB Vision : 6 10G USB 3.2 Gen 2, 1 20G USB 3.2 Gen 2×2 Type-C
- 4 COM RS-232/422/485, 3 SIM Socket, 32 Isolated DIO
- Max 4 external 2.5” SSD/HDD trays, Software RAID supported
- Compact M.2 Configurations : M.2 Key B, M.2 Key E, M.2 Key M
- Intel Deep Learning Boost (Intel DL Boost) and Intel Distribution of OpenVINO toolkit for AI Computing
- Optional supports advanced NVIDIA Ampere Architecture and NVIDIA Turing Architecture by low-profile graphics cards
Flexible Configuration
- Levels of Independent Low-profile PEG : NVIDIA RTX A2000, NVIDIA Tesla A2, NVIDIA Tesla T4, NVIDIA T1000
- Versatile product configuration for project requirements
- SIM sockets for multiple 5G/WiFi/BT/4G/LTE/GPRS/UMTS wireless connections
- PCIe expansions for multiple 10GigE M12 PoE+ LAN, 10GigE PoE+ LAN, 10GigE LAN, 10G SFP+, 2.5GigE PoE+ LAN, 2.5GigE LAN, M12 PoE+ LAN, PoE+ LAN, GigE LAN, LAN Switch, USB, or Independent Graphics
- Compact Expansions : Mini PCIe, M.2 Key B, and M.2 Key
Optimized Operation
- Max 200W power budget for independent graphics cards
- Multiple 5G/WiFi/BT/4G/LTE/GPRS/UMTS supports non-stop wireless data transfer
- Lockable SSD/HDD trays, RAID 0, 1, 5, 10 Data Protection
- DC 12V to 50V wide range power input
- Software Ignition Power Control for in-vehicle applications
- Anti-shock, Anti-vibration
- EN50155, EN50121-3-2
- Real-time capable with Intel Time Coordinated Computing (Intel TCC) and support for Time-Sensitive Networking (TSN)
- Smart System Management : Intel vPro, TPM 2.0, PXE, Wake on LAN, Watchdog Timer
