Description
-
-
- Industrial-grade NXP i.MX 8M Plus Quad Core Arm Cortex-A53 Processor, embedded Neural Processing Unit, up to 2.3 TOPS AI performance
- Supports up to 3840 x 2160 4K UHD
- 2 GigE LAN with 1 TSN supported
- 2 SIM sockets for multiple WiFi/BT/5G/4G/LTE/GPRS/UMTS
- Optional 2 CAN Bus support Flexible Data-rate and Optional 5-bit GPIO
- 9V to 55V wide range DC Power Input
- Fanless -25°C to 70°C operation
-
Feature Highlights
Computer Vision Platform
- NXP i.MX 8M Plus Quad Core Arm Cortex-A53 Processor
- Embedded Neural Processing Unit (NPU) delivers up to 2.3 TOPS AI performance
- 4GB LPDDR4 Memory
- Supports max 3840 x 2160 4K UHD
- 2 GigE LAN for Vision
- 2 USB 3.0 for Vision
- Lower Power Consumption
High-speed Connectivity
- PCIe 3.0 supports max 8GT/s data transfer
- Dual 10/100/1000 Ethernet, RJ45 Connector, TSN (Time Sensitive Networking) supported
- 2 USB 3.0 Type A, up to 5 Gbit/s
- 2 SIM sockets support multiple WiFi/BT/5G/4G/LTE/GPRS/UMTS wireless connections
- 2 COM RS-232/422/485
- 2 CAN Bus, optional 5-bit GPIO
Industrial Reliability
- Fanless -25°C to 70°C operation
- DC 9V to 55V wide range power input
- Optional supports Flexible Data-rate (CAN FD)
- Anti-shock, Anti-vibration
- EN50155, EN50121-3-2
- IEC 60068-2-27, IEC 60068-2-64
