Description
- LGA 1151 Socket supports Quad Core Intel® Xeon®/Core™ i7/i5/i3 Processor (Kaby Lake-S/Skylake-S) with C236 Chipset
- 2 DDR4 2133MHz SO-DIMM, up to 32GB (ECC/Non-ECC)
- Fanless, -40°C to 75°C Operating Temperature
- 10 Independent GigE LAN support up to 8 M12 IEEE 802.3at PoE+, dual LAN Bypass, iAMT 11.0
- Rugged X-coded M12 interface supports up to 10Gbps data transmission
- 2 Front-access 2.5″ SSD/HDD Tray support up to 4TB capacity & RAID 0, 1
- 3 Front-access SIM Card Socket for 3G/4G/LTE/WiFi/GPRS/UMTS
- Storage : 2 SSD Tray, 1 CFast, 2 SATA III
- 2-port CAN Bus, 3 Mini PCIe/mSATA, 1 M.2
- DVI-I, DVI-D and DisplayPort display interfaces, up to 4K displays
- 32 Isolated DIO, 8 USB 3.0, 4 COM
- 6V to 36V DC-in with 80V Surge Protection
- Configurable Ignition Power Control
